FBT Audio JMaxX 114A Active Loudspeaker

FBT Audio JMaxX 114A Active Loudspeaker

Regular price £629.00 GBP
Regular price Sale price £629.00 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

Low stock

FBT Audio JMaxX 114A Active Loudspeaker

The JMaxX 114A features a 14" LF woofer with 2" voice coil 1" exit throat HF compression driver with 1.4" voice coil 700W RMS LF, 200W RMS HF DSP with 4-EQ pre-sets all in an incredibly lightweight gas injected moulded polypropylene cabinet. 132 dB SPL.

The new FBT JMaxX 114A combines ease of use and versatility for many portable or installed sound applications: musicians, DJs, AVL contractors, rental sound reinforcement, corporate events, houses of worship, bars and clubs.

With its eye-catching gas-injected forms designed to virtually eliminate undesired enclosure resonance and reinforce strong low frequency performance, the 14-inch JMaxX 114A is equipped with FBT’s latest 90° x 60° HF horn design which delivers improved projection, accuracy, and dispersion of the mid and high frequencies.

Providing a myriad of possibilities for bands, DJs and solo artists, as well as for permanent installations, the JMaxX 114A is actually four loudspeakers in one. Derived from a decade of experience of portable sound reinforcement, the carefully tailored equalisation presets offer highly intelligible response for vocals and floor monitoring; slightly boosted response in lounge bar applications; punchy and forward sound for DJs and night venues; and a general-purpose EQ setting that mirrors the original and familiar FBTMaxX voicing.

The JMaxX 114 A features  FBT’s latest generation lightweight 700W + 200W Class D power amplifier with universal switch mode power supply, delivering abundant power and headroom to reproduce even the largest transients without distortion.

And a unique 14 Inch Low frequency driver. The 14" Driver fits inside a cabinet the size of a 12" Cabinet yet performs as good as a conventional 15".
This unique speaker.
The result is an amazingly compact speaker with all the power and clarity of a much larger speaker and weighing Just 14Kg this Speaker is a dream to transport.


Key Features:

  • 14" LF woofer with 2.5" voice coil
  •  1" exit throat HF compression driver with 1.4" voice coil
  •  Frequency response from 45Hz to 20 kHz
  •  Extremely lightweight: only 14Kg
  • 2-way, bi-amplified bass reflex design cabinet
  • 700W RMS LF, 200W RMS HF, Class D power amplifiers with switch mode power supply
  •  DSP with 4-EQ presets
  •  Control panel with: XLR IN and XLR LINK, Volume, EQ presets, HP filter, GND LFT switch
  • 2 x M10 suspension points, 35mm (1.3/8”) top-hat speaker stand socket, wall bracket mount flange plate
  • 90°H x 60°V constant directivity horn
  •  Stage monitor angling facility with 12°, 40° or 55° taper



Manufacture Specification:


Configuration: 2 Way
Frequency response: 45Hz - 20kHz
Low frequency woofer: 14" (2.5" VC)
High frequency driver: 1" (1.4" VC)
Maximum SPL cont/peak: 132 dB
Dispersion: 90 x 60
Input connector: XLR + 6.3mm Jack
Net Weight: 14kg
Built-in amplifier LF/HF: 700w/200w
Power cord: 5m IEC



This item is brand new. It comes sealed in retail packaging.

2 Year manufacture warranty included as standard + 3 years upon registration.

Demonstration of various FBT Audio models available at our London Show Room, Located at Unit 5, SE9 3TL

Part exchange accepted - get in contact for details.
