FBT Audio JMaxX 114A Active Loudspeaker
The JMaxX 114A features a 14" LF woofer with 2" voice coil 1" exit throat HF compression driver with 1.4" voice coil 700W RMS LF, 200W RMS HF DSP with 4-EQ pre-sets all in an incredibly lightweight gas injected moulded polypropylene cabinet. 132 dB SPL.
And a unique 14 Inch Low frequency driver. The 14" Driver fits inside a cabinet the size of a 12" Cabinet yet performs as good as a conventional 15".
This unique speaker.
The result is an amazingly compact speaker with all the power and clarity of a much larger speaker and weighing Just 14Kg this Speaker is a dream to transport.
Key Features:
- 14" LF woofer with 2.5" voice coil
- 1" exit throat HF compression driver with 1.4" voice coil
- Frequency response from 45Hz to 20 kHz
- Extremely lightweight: only 14Kg
- 2-way, bi-amplified bass reflex design cabinet
- 700W RMS LF, 200W RMS HF, Class D power amplifiers with switch mode power supply
- DSP with 4-EQ presets
- Control panel with: XLR IN and XLR LINK, Volume, EQ presets, HP filter, GND LFT switch
- 2 x M10 suspension points, 35mm (1.3/8”) top-hat speaker stand socket, wall bracket mount flange plate
- 90°H x 60°V constant directivity horn
- Stage monitor angling facility with 12°, 40° or 55° taper
Manufacture Specification:
This item is brand new. It comes sealed in retail packaging.
2 Year manufacture warranty included as standard + 3 years upon registration.
Demonstration of various FBT Audio models available at our London Show Room, Located at Unit 5, SE9 3TL
Part exchange accepted - get in contact for details.
